High Productivity Exterior Cultured Production Line Concrete Fence Panel Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | HTX |
| Certification: | POSI CERTIFICATE |
| Model Number: | HTX-P-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | 40000-200000/USD |
| Packaging Details: | Carton |
| Delivery Time: | 30Days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 50Sets/Month |
|
Detail Information |
|||
| Product Name: | Veneer Stone Production Line | Feature: | Automatic |
|---|---|---|---|
| Power: | 37.6KW | Voltage: | 220V |
| Dimension(L*W*H): | 1200*1800*2100 | ||
| High Light: | automatic fence panel machine,fence panel making machine,panel master fencing machine |
||
Product Description
High Productivity Exterior Cultured Production Line Concrete Fence Panel Machine
Concrete fence panel machine is a piece of equipment used in the construction industry to manufacture precast concrete fence panels. These machines are designed to automate the production process and increase efficiency.
Here's a general overview of how a concrete fence panel machine works:
Framework: The machine consists of a sturdy frame that supports various components and mechanisms required for the production process.
Concrete Mixing: The machine usually has a built-in concrete mixer or a separate concrete batching plant. Cement, aggregates, water, and additives are mixed together in the correct proportions to form concrete.
Moulds: The machine is equipped with molds or formwork that define the shape and dimensions of the fence panels. These molds are typically made of steel or other durable materials.
Reinforcement Placement: Depending on the design and strength requirements, the machine may have mechanisms to place reinforcement bars or mesh inside the molds. This reinforcement provides structural integrity to the fence panels.
Concrete Pouring: Once the molds are prepared, the machine pours the concrete mixture into the molds. The concrete is evenly distributed and compacted to ensure proper filling and eliminate air pockets.
Vibrating and Leveling: Vibrators are used to remove air bubbles and consolidate the concrete, ensuring a dense and uniform panel. The machine may also have mechanisms to level the concrete surface.
Curing: After pouring, the molds with the freshly poured concrete panels are usually moved to a curing area. Curing allows the concrete to harden and gain strength over time. The duration of curing can vary depending on the specific concrete mix and environmental conditions.
Demolding: Once the concrete has cured sufficiently, the molds can be opened, and the newly formed fence panels are removed. The panels are then typically stacked or transported to a storage area for further handling or distribution.
Specification:
| Name | Model | Specification | Size(mm) | Power(Kw) | Capacity(m2/day) | Weight(Kg) |
| Wet Cast Machinery | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 1000-1500 | 2000 |
| Wet Cast Machinery | HTX-P-02 | Chain drived;Auto feeding,auto vibration | 8000*1100*1600 | 4.05 | 800-1000 | 1500 |
Applications
Wet cast machinery, is suitable for different silicone molds, rubber molds and plastic molds, size range from 200*200mm to 1500*1500mm, available for producing the artificial stone both for paving tile molds, 3D wall molds, wall panel molds, roadside stone molds, retaining wall molds, wall cap molds, etc.
Support and Services
Wet Cast Machinery technical support and services include:
- On-site technical support and maintenance
- Expert assistance with installation and setup
- Remote and telephone troubleshooting and support
- Periodic maintenance and inspection
- Repair and replacement parts
- Technical training and user manuals
- Upgrades and software updates
