Fully Automatic Paver Stone Block Making Machine Building Material Machinery
Product Details:
| Place of Origin: | China |
| Brand Name: | HTX |
| Model Number: | HTX-P-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | 40000-200000/USD |
| Packaging Details: | Normally carton box or following customer's requirements for Foam CLC Lightweighted Concrete Cement Injection For House Partition And Heat Preservation |
| Delivery Time: | 30Days |
| Payment Terms: | L/C, D/A, D/P, T/T, MoneyGram |
| Supply Ability: | 500Sets/Month |
|
Detail Information |
|||
| Product Name: | Plastic Paver Factory Concrete Stone Production Line | Voltage: | 220V |
|---|---|---|---|
| Dimension(L*W*H): | 12000*1800* 2100 | Feature: | Automatic |
| Capacity: | 800-1000m2 | Power: | 12.7 KW |
| High Light: | Fully Automatic Paving Stone Making Machine,Building Concrete Paver Making Machine 220V,Automatic Paver Stone Block Making Machine |
||
Product Description
Fully Automatic Paver Stone Block Making Machine Building Material Machinery
Product Description
automatic production line concrete artificial stone machine In order to save labor as much as possible and reduce the workload of workers, The precast concrete production line making machine is divided into 15 parts from ingredients to packaging, which are connected and operated through a programmable control cabinet, each part and half part can work independently.wet casting doser machine Multiple function for production, it include unloading, painting, concrete dosing and stacking, and available usage for plastic molds of floor tile and terrazzo tile, silicone molds for artificial stone etc.The auto spray painting machine, has function for mold oil painting, stroll color painting and full color painting, also it can be turned on/off separately. This equipment is an upgraded version of the above blue equipment. 1. The feeding method is adjusted from horizontal unloading to bottom-up pumping and feeding. The feeding amount is more stable, and there will be no leakage or uneven feeding. 2. A weighing system is added, and there is a weighing device under the discharge opening, which can weigh 5-25kg of concrete, making the discharge volume more accurate. 3. A digital display PLC control system is added, which is easy to operate and more intelligent.
| Name | Model | Specification |
Size (mm) |
Power (Kw) |
Capacity (m2/day) |
Weight (Kg) |
| Artificial stone production line | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 800-1000 | 2000 |
| Artificial stone production line | HTX-P-02 | Chain drived;Auto feeding,auto vibration | 8000*1100*1600 | 4.05 | 600-800 | 1500 |
