Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine

Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine

Product Details:

Place of Origin: China
Brand Name: HTX
Certification: POSI CERTIFICATE
Model Number: HTX-P-01

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Price: 40000-200000/USD
Packaging Details: Carton
Delivery Time: 30Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50Sets/Month
Get Best Price Contact Now

Detail Information

Product Name: Curbstone Machine Voltage: 220V
Size: 1500*1300*2500cm Key Selling Points: High Productivity
Feature: Automatic Capacity: 1200-1500m2
High Light:

automatic fence panel machine

,

fence panel making machine

,

panel master fencing machine

Product Description

Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine



curbstone machine, also known as a curb making machine or curb forming machine, is a specialized piece of equipment used for the automated production of concrete curbstones or kerbstones. These machines are designed to streamline and optimize the manufacturing process, allowing for efficient and consistent production of curbstones with various shapes, sizes, and designs.

Here's a general overview of how a curbstone machine works:



Concrete Batching Plant: The curbstone machine is typically connected to a concrete batching plant or mixer. The batching plant accurately measures and combines cement, aggregates (such as sand and gravel), water, and additives to create the concrete mixture. The quality and consistency of the concrete mix are crucial for producing durable and high-quality curbstones.



Mold Preparation: The machine is equipped with molds or formwork that define the shape and dimensions of the curbstone. These molds can be customized to produce different curbstone profiles, including straight curbs, radius curbs, and interlocking curbs.



Concrete Feeding: The concrete mixture from the batching plant is fed into the curbstone machine. The machine may have a conveyor system or other mechanisms to transport the concrete to the mold or formwork.



Vibration and Compaction: Once the concrete is in the mold, the curbstone machine applies vibrations and compaction to ensure proper consolidation. Vibrations help remove air bubbles and settle the concrete evenly throughout the mold, resulting in curbstones with improved strength and durability.



Curing: After compaction, the molds with the freshly poured curbstones are usually moved to a curing area. Curing is a critical step that allows the concrete to gain strength and develop its desired properties. The curbstones may be covered or subjected to temperature and humidity control to optimize the curing conditions.



Demolding and Finishing: Once the curbstones have sufficiently cured and hardened, the molds are opened, and the finished products are demolded. The curbstones may undergo additional processes, such as surface finishing or edge profiling, to achieve the desired appearance and functionality.



Quality Control and Packaging: Throughout the production process, quality control measures are implemented to ensure that the curbstones meet the required standards. This may involve inspecting dimensions, surface quality, and strength properties. After quality control checks, the curbstones can be packaged and prepared for storage or transportation.



Curbstone machines can be fully automatic or semi-automatic, depending on the level of automation and the specific features of the machine. They are designed to minimize manual labor, increase productivity, and ensure consistent quality in curbstones production. These machines are widely used in road construction, landscaping, and urban development projects.



Specification:



Name Model Specification Size(mm) Power(Kw) Capacity(m2/day) Weight(Kg)
Wet Cast Machinery HTX-P-01

Hydraulic driving;Auto feeding;

vibrating and timing feeding

7000*1000*1800 12.7 1000-1500 2000
Wet Cast Machinery HTX-P-02 Chain drived;Auto feeding,auto vibration 8000*1100*1600 4.05 800-1000 1500





Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine 0Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine 1Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine 2Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine 3Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine 4Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine 5



Applications

Wet cast machinery, is suitable for different silicone molds, rubber molds and plastic molds, size range from 200*200mm to 1500*1500mm, available for producing the artificial stone both for paving tile molds, 3D wall molds, wall panel molds, roadside stone molds, retaining wall molds, wall cap molds, etc.

Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine 6Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine 7Fully Automatic Concrete Wall Fence Panels Making Machine Curbstone Machine 8



Support and Services



Wet Cast Machinery technical support and services include:

  • On-site technical support and maintenance
  • Expert assistance with installation and setup
  • Remote and telephone troubleshooting and support
  • Periodic maintenance and inspection
  • Repair and replacement parts
  • Technical training and user manuals
  • Upgrades and software updates
