Concrete Faux Classic Brick Panels Uhpc Concrete Machine Wet Cast Machinery
Product Details:
Place of Origin: | China |
Brand Name: | HTX |
Certification: | POSI CERTIFICATE |
Model Number: | HTX-P-01 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1Set |
---|---|
Price: | 15000-80000/USD |
Packaging Details: | Carton |
Delivery Time: | 30Days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 50Sets/Month |
Detail Information |
|||
Product Name: | Wet Cast Concrete Machinery | Feature: | High Efficiency Low Cost |
---|---|---|---|
Size: | 7000*1000*1800mm | Capacity: | 1200-1500m2 |
Usage: | Producing Artificial Stone Veneer | ||
Highlight: | automatic fence panel machine,fence panel making machine,panel master fencing machine |
Product Description
UhPC (Ultra-High Performance Concrete) machine refers to the equipment and machinery used in the production of ultra-high performance concrete. UhPC is an advanced type of concrete known for its exceptional strength, durability, and other superior properties. It is made by combining carefully selected materials and optimized mix designs to achieve high compressive strength and enhanced performance characteristics.
The manufacturing process of UhPC involves specialized equipment and techniques. Here are some key components and processes typically associated with UhPC concrete production:
1.Mixing Equipment: UhPC requires precise mixing of its constituent materials. High-shear mixers or planetary mixers are commonly used to ensure thorough blending and dispersion of the ingredients. These mixers are capable of achieving high intensity mixing to achieve the desired homogeneity and reduce the presence of voids or air pockets.
2.Raw Materials: UhPC typically includes a combination of fine powders, aggregates, and chemical admixtures. The specific materials used can vary, but they often include high-quality silica fume, quartz powder, ultra-fine sand, specially graded aggregates, and high-range water-reducing admixtures. These materials contribute to the unique properties of UhPC, such as high strength and improved durability.
3.Batching and Proportioning: Accurate batching and proportioning of the raw materials are crucial to ensure the desired characteristics of UhPC. Advanced computerized systems or automated batching equipment may be used to precisely measure and control the quantities of each component, maintaining consistency and reproducibility.
4.Mixing and Blending: The raw materials are introduced into the mixer in a specific sequence to achieve optimal distribution and dispersion. As mentioned earlier, high-shear mixers or planetary mixers are commonly used to achieve thorough blending and ensure a uniform mixture.
5.Formwork and Molding: Once the UhPC mixture is ready, it is poured or placed into molds or formwork to shape it into the desired forms, such as panels, beams, columns, or other structural elements. The formwork can be made of various materials, including steel, timber, or other suitable materials, depending on the specific requirements.
6.Curing: The UhPC elements are subjected to a controlled curing process to ensure proper hydration and development of strength. Curing methods can include steam curing, heat curing, or a combination of both. The aim is to optimize the hydration reactions and achieve the desired strength and durability properties.
7.Finishing and Surface Treatment: After the UhPC elements have cured, they may undergo finishing processes to achieve the desired surface texture, appearance, and dimensional accuracy. This can involve grinding, polishing, or other surface treatments to enhance the aesthetics and functional properties.
Specification:
Name | Model | Specification | Size(mm) | Power(Kw) | Capacity(m2/day) | Weight(Kg) |
Wet Cast Machinery | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 1000-1500 | 2000 |
Wet Cast Machinery | HTX-P-02 | Chain drived;Auto feeding,auto vibration | 8000*1100*1600 | 4.05 | 800-1000 | 1500 |
Applications
Wet cast machinery, is suitable for different silicone molds, rubber molds and plastic molds, size range from 200*200mm to 1500*1500mm, available for producing the artificial stone both for paving tile molds, 3D wall molds, wall panel molds, roadside stone molds, retaining wall molds, wall cap molds, etc.
Support and Services
Wet Cast Machinery technical support and services include:
- On-site technical support and maintenance
- Expert assistance with installation and setup
- Remote and telephone troubleshooting and support
- Periodic maintenance and inspection
- Repair and replacement parts
- Technical training and user manuals
- Upgrades and software updates
