3D Wall Concrete Production Line Concrete Artificial Stone Making Machine
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | HTX |
| Certification: | HTX-P-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | 15000-80000/USD |
| Packaging Details: | Normally carton box or following customer's requirements |
| Delivery Time: | 50Days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500Sets/Month |
|
Detail Information |
|||
| Name: | Wet Cast Concrete Machinery | Voltage: | 220V |
|---|---|---|---|
| Key Selling Points: | High Productivity | Capacity: | 800-1000m2 |
| Brick Type: | Concrete Dosing System | Weight: | 2000KG |
| Highlight: | 3D Wall Concrete Production Line,Wet Cast Dosing Concrete Production Line,Concrete Stone Making Wet Cast Machinery |
||
Product Description
3D Wall Concrete Production Line Concrete Stone Making Machine Artificial Stones Production Line Machine
Product Description
A curbstone casting machine is a specialized piece of equipment used in the production of curbstones, which are concrete or stone blocks used to edge roads, sidewalks, and other paved surfaces. Curbstone casting machines are designed to automatically dispense the ingredients needed for wet casting, and then extract the finished product from the mold or form.
The curbstone casting machine operates by first dispensing the dry ingredients from the hopper into the mixing chamber, where they are mixed with water and color pigments to create a wet concretemixture. The concrete mixture is then poured into the mold or form, where it is allowed to cure and harden. Once the curbstone has hardened, the demolding system extracts it from the mold or form, and it is ready for finishing and further processing.
Curbstone casting machines can be highly automated, with computerized controls to ensure precision and consistency throughout the manufacturing process. The machines can be designed to produce a variety of curbstone shapes and sizes, and can be adjusted to meet specific customer requirements in terms of color, texture, and finish.
Overall, curbstone casting machines are an important component of the construction and infrastructure industries, providing a cost-effective and efficient way to produce high-quality curbstones for use in roadways, sidewalks, and other paved surfaces. The machines can be designed to be modular, allowing manufacturers to add or remove specific components as needed to meet changing market demands.
Specifications
| Name | Model | Specification |
Size (mm) |
Power (Kw) |
Capacity (m2/day) |
Weight (Kg) |
|---|---|---|---|---|---|---|
| Artificial stone production line | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 1000-1200 | 2000 |
| Wet Cast Machinery | HTX-P-01A | Full Auto,timing feeding and vibration, weighing system; | 12000*1000*2000 | 9.1 | 800-1000 | 2000 |
Applications
Auto Concrete Wetcast System Production line advantages:More efficient production, can achieve 800M2 Per day (8hrs),Multiple function for production, it include unloading, painting, concrete dosing and stacking, and available usage for plastic molds of floor tile and terrazzo tile, silicone molds for artificial stone etc.Labors saving for production, 5-6 workers needed only, can largely reduce the labor cost of factory output.
If want to produce good quality artificial stone some machines are necessary.Based on production capacity, clients can choose simple machine, semi-auto production line, full auto production line.
Feature advantage
Henan HTX Group Co Ltd, specialized in designing, developing, producing and marketing of artificial stone molds, paving tile molds, concrete stamp molds, pillar molds, roman column molds, and relative machines and production lines.we have more than 200 mould designs and sizes. The updated silicone material make the stone mold more durable and have good characteristic. After use again and again,our updated silicone mould still have a clear & natural texture and without any deformation.
